What happened at your workbench today?

[Rhinochugger]

Marking out the catenary gantries at night inside, to machine the next day in the workshop.
View attachment 354408
The fire engine build slowly continues, should be finished by the end of the year.

That's where I fall down - marking out too unskilled, too impatient, too ...................... it never works

The one and only things that I really successfully marked out was six axle holes in a pair of steel frames for the 2-6-2 wot was pootling round the garden on Sunday afternoon

I managed to get all three pairs of holes in a straight line, the right distance apart and in the same place on each frame ................. at that point I peaked, and have never achieved anything like it since.



[grizzmo]

That's where I fall down - marking out too unskilled, too impatient, too ...................... it never works

The one and only things that I really successfully marked out was six axle holes in a pair of steel frames for the 2-6-2 wot was pootling round the garden on Sunday afternoon

I managed to get all three pairs of holes in a straight line, the right distance apart and in the same place on each frame ................. at that point I peaked, and have never achieved anything like it since.

These gantries don't need to be anywhere near as accurate as a loco chassis. Which is very good, as there not.
A bit of inaccuracy in the marking out, a bit in the machining and a bit in the filing to square the slots up .
They are a near enough is close enough model, I am not a rivet counter.
