This thread is to briefly describe the construction of a locomotive shed with an electrically operated door.

This engine shed is made of 2 parts:
a) a main building and
b) a door module.


My main motivation was the door construction!
So the main building is quite crude, I am not an artist like many on this forum ..... !!

This construction has just had the honor of an article in the web review:
MRH (Model Railroad Hobbyst) from August 2020


Normally it is in pdf and available for free but this article is in the paid part (Running extra).
So it's just $ 1.99. This review is mostly O, HO and N !! But there are articles which are very interesting.

The main element of this achievement is the motor block:


The following video shows the rolling shutter in operation.


P

playmofire

Registered
23 Oct 2010
7,089
744
North Yorks
This thread is to briefly describe the construction of a locomotive shed with an electrically operated door.

This engine shed is made of 2 parts:
a) a main building and
b) a door module.

View attachment 275564

My main motivation was the door construction!
So the main building is quite crude, I am not an artist like many on this forum ..... !!

This construction has just had the honor of an article in the web review:
MRH (Model Railroad Hobbyst) from August 2020

View attachment 275566

Normally it is in pdf and available for free but this article is in the paid part (Running extra).
So it's just $ 1.99. This review is mostly O, HO and N !! But there are articles which are very interesting.

The main element of this achievement is the motor block:

View attachment 275565

The following video shows the rolling shutter in operation.

Great idea and well executed.

I like the end shot from the loco running in.

ARIA31

ARIA31

Registered
3 Oct 2017
178
37
71
Toulouse - France
Totally right. There are 2 end stops switches.
The shutter is sliding in 2 U rails placed on each side.
The switches are at the top and the bottom on one side.

. 587.JPG

This is a very simple control device with a DPDT control switch.

Greg Elmassian

Greg Elmassian

Registered
8 Mar 2014
4,445
660
San Diego
www.elmassian.com
Nice! I have seen ones that flip the switch, and have a diode as I remember, so once it hits the limit, the motor will only run in the reverse direction. I assume your setup has a similar logic!

Thanks! Greg

ARIA31

ARIA31

Registered
3 Oct 2017
178
37
71
Toulouse - France
I tried this solution with diodes but at the end I choose to use the following circuit

electrical circuit.jpg

However despite very simple , I tested that before installation on the shed !! :)
